Mechanical Level Gauge

+1

1

Other

Type

Brand New

Condition

Store address

Dar es Salaam • Ilala

Kigamboni, Dar es Salaam

Closed

• Mon - Sat, 08:30-17:45

Measuring Range • 1 to 20 metres Liquid Density • Minimum Specific Gravity: 0.8 Tank Pressure • Designed for non-pressurized (atmospheric) tanks only Maximum Temperature • Up to 150°C depending on material selected Construction Materials • Gauge Board: Aluminium • Wetted Parts: SS304 / SS316 or PP depending on application • Float: SS or PP based on chemical compatibility Types • Guided type: Uses guide wires to prevent float drifting (for tanks with moderate turbulence) • Unguided type: Float moves freely (for calm liquids) Pointer Movement • Pointer shows TOP when tank is empty • Pointer shows BOTTOM when tank is full Accessories / Options • Seal pot • Alarm or switch integration • Gauge boards supplied in 1-meter modular sections • Custom markings and indicator plates
