Module type: 550d(hpm)72(18c)
maximum power (pmax): 550 w
open circuit voltage (voc): 49.82 v
maximum power voltage (vmp): 42.00 v
maximum system voltage: 1500 v dc
maximum series fuse rating: 25 a
short circuit current (isc): 13.97 a
maximum power current (imp): 13.10 a
power selection: 0 ~ +5 w
weight: 25.8 kg
size (l×w×h): 2279×1134×30 mm
safety class: class ii
cell type: mono-crystalline
no. of cells: 144 (6×24)
testing conditions:
am1.5, irradiance = 1000 w/m2, temp = 25°c
tolerance:
pmax ±3%, voc ±3%, isc ±4%
