Features
Self-suction - self-priming pump
Eccentric of self-adjusting blades
Rust treatment
Suitable for the diesel transfer (ask for other liquids)
Agricultural, building, public work and industrial usesTechnical data
Free flow: 70-80 l/min
Motor: 0.37 kW
Consumption: 12 VDC: 35-53 A · 24 VDC: 25-35 A
Operation: S1
Motor speed: 1,500 rpm
Protection: IP-55
Pressure: 1.4 bar
Max. suction length: 2.7 m
Priming pipe suction: 5 m
Ambient Temperature: -20 oC / +50 oC
Connection: F1" BSP flanges and threads
Components
Recirculation bypass valve
Self-ventilated dust-protected motor
ON/OFF switch (the model with switch)
3 m cable with clamps
Cast-iron pump body
