Technical Specifications
Input voltage: 110–240V AC, 50/60Hz
Motor voltage: 24V DC
Motor power supply: Battery-driven (2 × 12V batteries)
Battery charger output: 1.3A @ 27.6V (≈38W)
Current consumption (motor): ~13A
Gate Capacity & Performance
Maximum gate weight: 600 kg
Maximum gate length: up to 100 m
Gate speed: up to ~35–36 m/min
Motor push force:
Starting: 30 kgf
Rated: 17 kgf
Backup & Power Features
Battery backup: Yes (continues working during power outages)
Standby operations:
Up to ~200+ cycles (power-saving mode)
Solar compatibility: Supported
Receiver & Remote Control
Receiver type: Code-hopping multichannel (secure)
Frequency: 433.92 MHz
Remote capacity: Up to 1,500 remotes
Smart Features
Smartphone control via mobile app
Automatic setup (self-learning limits)
Adjustable speed (open/close)
Autoclose function
