Key Technical Specifications
• Rated Power: 1000VA / 1000W
• Battery Input: 12V DC
• AC Output: 230V AC, 50/60Hz, pure sine wave
• Solar Charger (MPPT): 600W rated power, 150V DC max VOC, 20–150V DC MPPT range, 40A max charging current
• AC Charger: 230V AC input, 13.5V DC output, default 30A (max 60A)
• Interface & Protection: USB (Wi-Fi/GPRS optional), IP21 rating, Class 1, programmable supply options (PV / Battery / Grid).
