Nominal Voltage: 51.2 Vdc
Rated Capacity: 100 Ah
Rated/Nominal Energy: 5.12 kWh per module
Battery Chemistry: Lithium Iron Phosphate (LiFePO4 / LFP), known for high safety and long thermal stability
Cycle Life: ≥ 6000 cycles at 25°C (0.5C/0.5C, 70% End of Life)
Max Charge/Discharge Current: 100 A (nominal), up to 125 A max continuous
Operating Temperature: Charge from 0°C to 55°C; Discharge from -20°C to 55°C
Dimensions & Weight: 440 × 570 × 133
Protection & Communication: Intelligent BMS with over-charge, over-discharge, over-current, and temperature protection; supports CAN2.0 and RS485 communication.
Scalability: Requires a high-voltage control box (PDU) and supports stacking/series configuration of multiple modules (typically 3 to 12+ modules per cluster depending on the high-voltage inverter setup).
