Features
type
10kw-1φ-4way
model
ac100tn4dkc/tc
system
mode
cooling only
capacity
cooling [kw]
3.0 / 10.0 / 12.0 kw
power input
cooling 1)
0.6/3.125/4.7 kw
current input
cooling
3.0/14.8/20.4 a
fan
type
turbo fan
motor (output) [w]
97 w
number of unit (ea)
1 ea
air flow rate (high / mid / low) [cmm]
30.3/24.3/19.4 cmm
drain
drain pipe (φ,mm)
vp25 (od 32,id 25)
sound
sound pressure (high / mid / low) [db(a)]
43/38/33 dba
external dimension (indoor unit)drain pump
built in
drain pump max. lifting height/displacement
750 /24
compressor
type
twin bldc roaty
model name
ug8t300fubju
output(kw)
2.82 kw
oil (type)
poe
oil (initial charge) [cc]
1200 cc
operating temp. range
cooling (°c)
-15 ~ 50 °c
smart
wifi kit
yes
app connectivity
smartthings app support
yes
piping kit
yes
